Product Summary

The LMV7271MG is a rail-to-rail input low power comparator, which is characterized at supply voltage 1.8V, 2.7V and 5.0V. It consumes only 9uA supply current per channel while achieving a 800ns propagation delay.

Parametrics

Absolute maximum ratings: (1)Supply Voltage (V+ - V-): 6V; (2)Infrared or Convection (20 sec.): 235℃; (3)Wave Soldering (10 sec.): 260℃; (4)Storage Temperature Range: -65℃ to +150℃; (5)Junction Temperature: +150℃.

Features

Features: (1)Single or Dual Supplies; (2)Ultra low supply current 9μA per channel; (3)Low input bias current 10nA; (4)Low input offset current 200pA; (5)Low guaranteed VOS 4mV; (6)Propagation delay 880ns (20mV overdrive); (7)Input common mode voltage range 0.1V beyond rails; (8)LMV7272 is available in micro SMD package.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LMV7271MG
LMV7271MG
National Semiconductor (TI)
Comparator ICs
Data Sheet
0-1000: $0.27
1000-2000: $0.27
LMV7271MG/NOPB
LMV7271MG/NOPB
National Semiconductor (TI)
Comparator ICs SINGLE 1.8V LOW PWR COMPARATOR W/ RRI
Data Sheet
0-1: $0.54
1-10: $0.48
10-25: $0.43
25-100: $0.29
LMV7271MGX/NOPB
LMV7271MGX/NOPB
National Semiconductor (TI)
Comparator ICs
Data Sheet
0-1: $0.54
1-10: $0.48
10-25: $0.43
25-100: $0.29
LMV7271MGX
LMV7271MGX
National Semiconductor (TI)
Comparator ICs
Data Sheet
0-3000: $0.27
