Product Summary
The TLP181 is a small outline coupler, suitable for surface mount assembly. It consists of a photo transistor optically coupled to a gallium arsenide infrared emitting diode. Since it is smaller than DIP package, it’s suitable for high-density surface mounting applications such as programmable controllers.
Parametrics
Absolute maximum ratings: (1)Storage temperature range, Tstg: -55 to 125 ℃; (2)Operating temperature range, Topr: -55 to 110 ℃; (3)Lead soldering temperature, Tsol: 260 (10s) ℃; (4)Total package power dissipation, PT: 200 mW; (5)Total package power dissipation derating (Ta ≥ 25℃), ΔPT / ℃: -2.0 mW / ℃; (6)Isolation voltage (AC, 1min., R.H. ≤ 60%), BVS: 3750 Vrms.
Features
Features: (1)Collector-emitter voltage: 80V (min); (2)Current transfer ratio: 50% (min) Rank GB: 100% (min); (3)Isolation voltage: 3750Vrms (min); (4)Operation Temperature:-55 to 110℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLP181(GB,F) |
Toshiba |
Transistor Output Optocouplers 80V Photocoupler 3750 Vrms 100 to 600 |
Data Sheet |
Negotiable |
|
||||||||||||||||||||
 |
TLP181(TPR,F) |
Toshiba |
Transistor Output Optocouplers DC Transistor Miniflat |
Data Sheet |
Negotiable |
|
||||||||||||||||||||
|
TLP181GB |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||||||||||
|
TLP181(GB,F,T) |
Toshiba |
Transistor Output Optocouplers DC Transistor Miniflat |
Data Sheet |
Negotiable |
|
||||||||||||||||||||
 |
TLP181(F,T) |
Toshiba |
PHOTOCOUPLER TRANS-OUT 4-SMD |
Data Sheet |
|
|
||||||||||||||||||||
|
TLP181 |
|
PHOTOCOUPLER TRANS OUT 6MFSOP-4 |
Data Sheet |
Negotiable |
|
||||||||||||||||||||
|
TLP181(GR-TPR) |
|
PHOTOCOUPLER TRANS OUT 6MFSOP-4 |
Data Sheet |
Negotiable |
|
||||||||||||||||||||
|
TLP181(GR-TPL,F) |
Toshiba |
Transistor Output Optocouplers 80V Photocoupler 3750 VRMS 100 to 300 |
Data Sheet |
|
|
||||||||||||||||||||
