AT24C02BN-SH-T

Two-wire, Serial Interface, Schmitt Trigger, Filtered Inputs, SOP8, Automotive Serial EEPROM

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.06~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.06~0.10

PartNumber:: AT24C02BN-SH-T

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kevin Foley's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-27

From Other Seller

Part Number:AT24C02BN-SH-T
US $0.06 - 0.10
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C02BN-SH-T is a Two-wire Automotive Temperature Serial EEPROM. It provides 2048 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 256 words of 8 bits each. The AT24C02BN-SH-T is optimized for use in many automotive applications where low-power and low-voltage operation are essential. The AT24C02BN-SH-T is available in space-saving 8-lead JEDEC SOIC and 8-lead TSSOP packages and is accessed via a two-wire serial interface. In addition, the device is available in 2.5V (2.5V to 5.5V) versions.

Parametrics

AT24C02BN-SH-T absolute maximum ratings: (1)Operating Temperature:-55℃ to +125℃; (2)Storage Temperature:-65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground:-1.0V to +7.0V; (4)Maximum Operating Voltage:6.25V; (5)DC Output Current:5.0 mA.

Features

AT24C02BN-SH-T features: (1)Medium-voltage and Standard-voltage Operation: 2.5 (VCC = 2.5V to 5.5V); (2)Automotive Temperature Range:–40℃ to 125℃; (3)Internally Organized 128 x 8 (1K), 256 x 8 (2K), 512 x 8 (4K) or 1024 x 8 (8K); (4)Two-wire Serial Interface; (5)Schmitt Trigger, Filtered Inputs for Noise Suppression; (6)Bidirectional Data Transfer Protocol; (7)400 kHz (2.5V) Compatibility; (8)Write Protect Pin for Hardware Data Protection; (9)8-byte Page (1K, 2K) or 16-byte Page (4K, 8K) Write Modes; (10)Partial Page Writes are Allowed; (11)Self-timed Write Cycle (5 ms max); (12)High-reliability: Endurance: 1 Million Write Cycles, Data Retention: 100 Years; (13)8-lead JEDEC SOIC and 8-lead TSSOP Packages.
